Madone SL 7 Gen 8
- 30,831.50
- 30,831.50
- Unit price
- per
Split your payments into 4 with tabby. No interest, no fees!
+
+
Overview
Features
Specs
Sizing
Geometry
Madone SL 7 Gen 8 - Madone SL 7 Gen 8
is a lightweight aero road bike that brings elite racing tech to a lower price point with a more economical OCLV 500 Carbon layup than its SLR sibling. A Shimano 105 Di2 electronic groupset gives you lightning-fast electronic shifting and pairs with alloy handlebars to keep the price down. Plus, it's topped off with carbon wheels for extra lightweight performance.
the walktrough
Our lightest madone SL Disc Ever
New light and fast aero tube shaping paired with light-yet-economical 500 Series OCLV Carbon makes Gen 8 our lightest Madone SL Disc f/s ever and the ideal climbing bike.
Redefins what fast looks like
Revolutionary new Full System Foil aero tube shapes improve airflow over the whole bike while maintaining the lightness climbers crave. Plus, the bike’s entire rider system was meticulously designed and rigorously tested to be faster everywhere.
80% more vertically compliant IsoFlow
We refined our race-focused comfort tech to be lighter and have nearly double the vertical compliance so you can ride stronger longer.
Rooted in racing
Madone SL was informed by feedback from Lidl-Trek's fastest sprinters and climbers.
Adjustable aero cockpit
Madone Gen 8 features hoods that are narrower than the drops so you can adjust your positioning to prioritize aerodynamics or power. Plus, the two-piece design lets you quickly and easily dial in your fit.
Add-on aero bottles to make your whole bike faster
Add-on RSL Aero Bottles and Cages were designed with Madone Full System Foil aero shapes to make the whole rider system even faster.
Shimon Ultegra Di2
Ultegra Di2 R8100 is Shimano's most inspired drivetrain, packed with innovative, game-changing features. HYPERGLIDE+ technology allows for crisp, seamless shifts both up and down the gear range, even during maximal efforts. The new Di2 shifting system introduces Shimano's exclusive wireless integrated circuit, and the move to a 12 speed cassette ensures you have all the gearing you need. Ergonomics and aerodynamics have been enhanced at every turn, and you can set up the drivetrain just the way you like it via Shimano’s user-friendly E-Tube app.
*Please note - spec applies to all sizes unless listed separately
- Frame
- 500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chainkeeper, T47 BB, flat mount disc, UDH, 142x12mm thru axle
- Fork
- Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle
- Weight
- ML - 7.87 kg / 17.36 lbs (with TLR sealant, no tubes)
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).
- Battery
- Shifter
- Front derailleur
- Rear derailleur
- Shimano Ultegra R8150 Di2, 34T max cog
- *Crank
- Bottom bracket
- Cassette
- Shimano Ultegra R8101, 11-34, 12 speed
- Chain
- Shimano Ultegra/XT M8100
- Max chainring size
- 1x: 54T, 2x: 56/43
- Wheel front
- Wheel rear
- Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, Shimano 11/12-speed freehub, 142x12mm thru axle
- Skewer front
- Skewer rear
- Bontrager Switch chamfered thru axle, removable lever
- Tire
- Tire part
- Bontrager TLR sealant, 6oz
- Max tire size
- 32mm (as measured, see manual for details)
- Saddle
- Seatpost
- *Handlebar
- Handlebar tape
- *Stem
- Brake rotor
- Rotor size
- Max brake rotor sizes: 180mm front, 160mm rear
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice. Prices shown are manufacturer's suggested retail prices.
Weights are based off pre-production products at time of publication. Weights may vary in final production.
Size
XS (47cm)
S (50cm)
M (52-54cm)
ML (56cm)
L (58cm)
XL (60-62cm)
Rider Height
143 - 158 cm
4'8" - 5'2"
158 - 162 cm
5'2" - 5'4"
162 - 173 cm
5'4" - 5'8"
173 - 179 cm
5'8" - 5'10"
179 - 188 cm
5'10" - 6'2"
188 - 213 cm
6'2" - 7'0"
Inseam
67 - 74 cm
26" - 29"
74 - 76 cm
29" - 30"
76 - 81 cm
30" - 32"
81 - 84 cm
32" - 33"
84 - 88 cm
33" - 35"
88 - 100 cm
35" - 39"
Geometry
All measurements provided in cm unless otherwise noted.
| Frame size letter | Wheel size | A — Seat tube | B — Seat tube angle | C — Head tube length | D — Head angle | E — Effective top tube | G — Bottom bracket drop | H — Chainstay length | I — Offset | J — Trail | K — Wheelbase | L — Standover | M — Frame reach | N — Frame stack | Front center | Saddle rail height min (w/short mast) | Saddle rail height max (w/short mast) | Saddle rail height min (w/tall mast) | Saddle rail height max (w/tall mast) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 700c | 40.4 | 73.8° | 10.0 | 71.6° | 51.7 | 7.2 | 41.0 | 5.0 | 6.1 | 97.1 | 70.4 | 37.0 | 50.7 | 57.2 | 54.9 | 61.2 | 59.2 | 65.4 |
| S | 700c | 44.0 | 73.8° | 12.1 | 72.2° | 53.2 | 7.2 | 41.0 | 4.5 | 6.2 | 97.6 | 73.4 | 37.8 | 53.0 | 57.7 | 58.5 | 64.8 | 62.8 | 69.0 |
| M | 700c | 47.6 | 73.6° | 13.6 | 72.9° | 54.5 | 7.0 | 41.0 | 4.5 | 5.8 | 98.1 | 76.2 | 38.4 | 54.6 | 58.2 | 62.1 | 68.4 | 66.4 | 72.6 |
| ML | 700c | 51.2 | 73.4° | 15.0 | 73.5° | 55.7 | 7.0 | 41.0 | 4.0 | 5.9 | 98.0 | 79.0 | 38.9 | 56.2 | 58.1 | 65.7 | 72.0 | 70.0 | 76.2 |
| L | 700c | 54.8 | 73.4° | 17.2 | 73.8° | 56.8 | 6.8 | 41.1 | 4.0 | 5.7 | 99.0 | 82.0 | 39.4 | 58.2 | 58.9 | 69.3 | 75.6 | 73.6 | 79.8 |
| XL | 700c | 60.9 | 73.4° | 20.1 | 73.9° | 58.4 | 6.8 | 41.2 | 4.0 | 5.7 | 100.7 | 86.3 | 40.2 | 61.0 | 60.4 | 75.4 | 81.7 | 79.7 | 85.9 |
